OLYMPUS LOCK – 500DR – Cabinet Door Deadbolt Lock – CCL R1 – 15/16 Cylinder – Satin Chrome – KA 4T3 – Grade 1
OLYMPUS LOCK – 500DR – Cabinet Door Deadbolt Lock – CCL R1 – 15/16″ Cylinder – Satin Chrome – KA 4T3 – Grade 1
CCL R1 Keyway Cabinet Door Deadbolt Lock. Easily rekeyable via rear set screws.
Specifications:
- Function: Cabinet Door Lock
- Cylinder: R Series (equivalent to CCL R1 system) w/ 2 keys per lock
- Keyed Alike: KA 4T37526
- Cylinder diameter: 15/16″
- Barrel Diameter: 7/8″
- Functions: Key removable in locked or unlocked position. Standard function locks are non-handed
- Body: Zinc die cast
- Finish: 26D – Satin Chrome
- Includes: 2 keys, 56-1 bar strike, lock mounting screws
- Certifications: Passed ANSI/BHMA A156.11 Grade 1 performance requirements
Downloads:
- Spec Sheet / Dimensions
- Installation Instructions
- Template
